S355JR Steel Bailey Bridge Reinforcement Compact Bailey Bridge ODM

Bailey Bridges Description:

Bailey Bridges which are portable steel bridge have been widely used in various fields, its most important feature is to achieve a variety of spans, bear carrying capacity, light and handy components, easy to dismantle and strong adaptability can be quickly completed with simple tools and manpower.

The surface protection can be paint or hot-dip galvanized.

Bailey Bridges Specifications:

Bailey Bridges Introduction

Bailey Bridge is a standard bridge equipment, adopted extensively and the most popular in the world.

Bailey Bridges Advantage

Possessing the features of simple structure,
convenient transport, speedy erection
easy disassembling,
heavy loading capacity,
great stability and long fatigue life
being capable of an alternative span, loading capacity


Bailey Bridges Features

1. High strength and big stiffness, relative to the concrete bridge can be reduced trabecular high and self-respect
2. Due to the steel isotropic, quality of a material is uniform and modulus of elasticity, that make steel bridge in the working condition and calculation compared with the assumption
3. Bailey bridge generally prefabricated in factory, site assembled by pins and bolts; the construction period is short, processing convenient and not affected by seasonal effect.
4. Bailey bridge is suitable for industrialized manufacture and very convenient to transport.
5. Bailey bridge is easy to repair and replace, long lifetime, material can be recycled.


Bailey Bridges Application

Infrastructure maintenance and repair: The Bailey bridge can be utilized during the maintenance and repair of existing bridges or transportation routes. It can serve as a temporary detour or bypass while repairs or upgrades are being carried out on a permanent bridge, ensuring minimal disruption to traffic flow. Once the repairs are complete, the Bailey bridge can be disassembled and redeployed elsewhere.

Special events and festivals: The Bailey bridge has been utilized for temporary pedestrian bridges during special events, festivals, or public gatherings. It offers a secure and convenient way to manage large crowds and ensure the smooth flow of pedestrian traffic.

Mixture form to erect all kinds of Bailey Bridges

Temporary Bridges, Emergency Bridges and Fixed Bridges.
Using the bridge equipment, the suspension bridges of varied span can be erected.
The bridge has the advantages of few components, light weight and low cost.
Bailey Bridge requires no special tools or heavy equipment for construction, the bridge elements are small enough to be carried in, and the bridge is strong enough to carry. It is considered a great example of military engineering.

The compact 200 panel bridge: The compact 200 panel bridge is similar to the compact 100 panel bridge from their appearance. The difference is its increased panel height to 2.134m. It employed the method of alternating joints between Reinforcement Chords and the joints between panels. This method can decrease inelastic deformation caused by the oversized pinholes.
Pre-arch method is used to additionally cut down mid-span and vertical deflection to a larger degree.

Bailey Bridges Competitive Advantage:

Heavy loading capacity

Great stability

Long fatigue life

Light weight

Low cost

Easy and fast erection

Evercross Steel Bridges Overview:
